SKU: TLPN137(TP1,F)
Manufacture : Toshiba
Mfr Part Number :TLPN137
Product Category :In Stock For Purhcase Supplier Photocoupler (photo-IC output) Optocoupler Logic-Out Open Collector DC-IN 1-CH 8-Pin PDIP SMD T/R
0.0 (0 Reviews)
0 Sold
$0.00 $0.00
Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity:
-
+
  • TLPN137(TP1,F)
  • TLPN137(TP1,F)
1/1
  • TLPN137(TP1,F)
  • Description
  • Please Read
Product Attribute          Attribute Value
Manufacture

Toshiba

Mfr Part Number

TLPN137

Datasheet

→View  TLPN137 Datasheet PDF

Feature 5V supply voltage
Application Scope Communication interface / Measurement instrumentation / PLC
Function High-speed
Number of Circuits 1
Output Interface open-collector
RoHS Compatible Product(s) (#) Available
EU RoHS Compliant
ECCN (US) EAR99
Part Status Active
Automotive No
PPAP No
Logic Gate Type Inverter
Number of Channels per Chip 1
Maximum Data Rate 10MBd(Typ)
Polarity Inverting
Direction Type Uni-Directional
Minimum Isolation Voltage (Vrms) 5000
Typical Rise Time (us) 0.012
Typical Fall Time (us) 0.003
Maximum Propagation Delay Time (ns) 100
Standard CSA|cUL|UL
Input Type DC
Output Type Open Collector
Maximum Forward Current (mA) 20
Maximum Continuous Output Current (mA) 50
Minimum Forward Voltage (V) 1.45
Typical Forward Voltage (V) 1.55
Maximum Forward Voltage (V) 1.7
Maximum Reverse Voltage (V) 5
Maximum Power Dissipation (mW) 85
Minimum Operating Temperature (°C) -40
Maximum Operating Temperature (°C) 85
Lead Shape Gull-wing
Toshiba Package Name →View DIP8
Package Image
Pins 8
Mounting Through Hole/Surface Mount
Width×Length×Height (mm) 9.66×7.62×3.65
Package Dimensions
CAD data
(Symbol, Footprint and 3D model)
→View Download from UltraLibrarian<sup>®</sup> in your desired CAD format (Note) Download from UltraLibrarian® in your desired CAD format (Note)
