• KIOXIA CM6-V Enterprise - 3DWPD Mixed Use SSD 12.8TB, U.3 KCM61VUL12T8
1/1
  • KIOXIA CM6-V Enterprise - 3DWPD Mixed Use SSD 12.8TB, U.3 KCM61VUL12T8

KIOXIA CM6-V Enterprise - 3DWPD Mixed Use SSD 1.6TB, U.3 KCM61VUL1T60

SKU: KCM61VUL1T60
2.5-inch (U.3) 15mm ,1,600 GB, 3DWPD, BiCS FLASH™ Gen4 3D TLC Flash Memory
0.0 (0 Reviews)
0 Sold
$0.00 $730.46
Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity:
-
+
  • KIOXIA CM6-V Enterprise - 3DWPD Mixed Use SSD 12.8TB, U.3 KCM61VUL12T8
  • KIOXIA CM6-V Enterprise - 3DWPD Mixed Use SSD 12.8TB, U.3 KCM61VUL12T8
1/1
  • KIOXIA CM6-V Enterprise - 3DWPD Mixed Use SSD 12.8TB, U.3 KCM61VUL12T8
  • Description
  • Specifications CM6-V
  • Please Read

CM6-V Series Enterprise SSD

Enterprise NVMe™ Mixed-use SSD

The CM6-V series is a mixed-use SSD that is optimized to support a broad range of enterprise applications and associated workloads, including high performance computing, online transaction processing, IoT and edge computing, media streaming. Built on PCIe® 4.0 and NVMe™1.4 technology, the CM6 Series SSDs deliver excellent performance up to 1.4M IOPS (random read) and 350 KIOPS (random write), with maximum power consumption of 25 W.

Featuring KIOXIA Corporation’s 96-layer BiCS FLASH™ 3D TLC memory, the CM6-V Series of enterprise NVMe™ SSDs delivers 3 DWPD (Drive Writes Per Day) of endurance and supports storage capacities up to 12.8 TB, making them ideally suited for read and write mixed-use enterprise applications.


Base Model Number KCM61VUL1T60
Capacity 1,600 GB
lnterface PCIe® 4.0, NVMe™ 1.4
lnterface Speed 64 GT/s (Gen4 1x4, 2x2)
Flash Memory Type BiCS FLASH™ TLC
Sustained 128 KiB Sequential Read 6,900 MB/s
Sustained 128 KiB Sequential Write 2,800 MB/s
Sustained 4 KiB Random Read 1,300 K IOPS
Sustained 4 KiB Random Write 215 K IOPS
Supply Voltage 12 V ± 10 % ,3.3 Vaux ± 15 %
Power Consumption (Active) 16 W Typ.
Power Consumption (Ready) 5 W Typ.
MTTF 2,500,000 hours
Warranty 5 years
DWPD 3
Height 15.0 mm + 0, - 0.5 mm
Width 69.85 ± 0.25 mm
length 100.45 mm Max.
Weight 130 g Max.
Case Surface Temperature (Operating) 0°C to 70°C
Humidity (Operating) 5 % to 95 % R.H.
Vibration (Operating) 21.27 m/s2{ 2.17 Grms } ( 5 to 800 Hz )
Shock (Operating) 9,800 m/s2{ 1,000 G } ( 0.5 ms duration )

Key Features Key Applications
PCIe® 4.0, NVMe™ 1.4 specification compliant Data warehousing
Form factor: 2.5-inch, 15mm Z-height Online transaction processing (OLTP)
(transactional and relational databases)
Proprietary KIOXIA architecture: controller, firmware and BiCS FLASH™ 96-layer 3D TLC memory Business intelligence
SFF-TA-1001 conformant (U.3), works with Tri-mode controllers and backplanes Artificial intelligence and machine learning
Dual-port design for high availability applications
6th generation, two-die failure recovery and double parity protection
High performance with lower power consumption
Power loss protection (PLP) and end-to-end data protection
Suited for 24x7 enterprise workloads
Data security options: SIE, SED, FIPS 140-2[1, 2, 3, 4, 5]
Six power mode settings









Documents


Base Model Number KCM61VUL12T8 KCM61VUL6T40 KCM61VUL3T20 KCM61VUL1T60 KCM61VUL800G
Capacity 12,800 GB 6,400 GB 3,200 GB 1,600 GB 800 GB
Basic Specifications
lnterface PCIe® 4.0, NVMe™ 1.4
lnterface Speed 64 GT/s (Gen4 1x4, 2x2)
Flash Memory Type BiCS FLASH™ TLC
Performance in single port (1x4) mode (Up to)
Sustained 128 KiB Sequential Read 6,900 MB/s
Sustained 128 KiB Sequential Write 4,000 MB/s 4,200 MB/s 2,800 MB/s 1,400 MB/s
Sustained 4 KiB Random Read 1,400 K IOPS 1,300 K IOPS 880 K IOPS
Sustained 4 KiB Random Write 325 K IOPS 350 K IOPS 215 K IOPS 100 K IOPS
Power Requirements
Supply Voltage 12 V ± 10 % ,3.3 Vaux ± 15 %
Power Consumption (Active) 21 W Typ. 20 W Typ. 19 W Typ. 16 W Typ. 14 W Typ.
Power Consumption (Ready) 5 W Typ.
Reliability
MTTF 2,500,000 hours
Warranty 5 years
DWPD 3
Dimensions
Height 15.0 mm + 0, - 0.5 mm
Width 69.85 ± 0.25 mm
length 100.45 mm Max.
Weight 130 g Max.
Environmental
Temperature (Operating) 0°C to 70°C
Humidity (Operating) 5 % to 95 % R.H.
Vibration (Operating) 21.27 m/s2{ 2.17 Grms } ( 5 to 800 Hz )
Shock (Operating) 9,800 m/s2{ 1,000 G } ( 0.5 ms duration )
  • Product image may represent a design model.
  • Definition of capacity: KIOXIA Corporation defines a megabyte (MB) as 1,000,000 bytes, a gigabyte (GB) as 1,000,000,000 bytes and a terabyte (TB) as 1,000,000,000,000 bytes. A computer operating system, however, reports storage capacity using powers of 2 for the definition of 1GB = 2^30 = 1,073,741,824 bytes and therefore shows less storage capacity. Available storage capacity (including examples of various media files) will vary based on file size, formatting, settings, software and operating system, such as Microsoft Operating System and/or pre-installed software applications, or media content. Actual formatted capacity may vary.
  • GT/s: Giga Transfers per second.
  • A kibibyte (KiB) means 2^10, or 1,024 bytes.
  • MTTF (Mean Time to Failure) is not a guarantee or estimate of product life; it is a statistical value related to mean failure rates for a large number of products which may not accurately reflect actual operation. Actual operating life of the product may be different from the MTTF.
  • DWPD: Drive Writes Per Day. One full drive write per day means the drive can be written and re-written to full capacity once a day every day for the specified lifetime. Actual results may vary due to system configuration, usage and other factors.
  • Read and write speed may vary depending on various factors such as host devices, software (drivers, OS etc.), and read/write conditions.
  • IOPS: Input Output Per Second (or the number of I/O operations per second).
  • [1] The Sanitize Instant Erase (SIE), Self-Encrypting Drive (SED), FIPS (Federal Information Processing Standards) optional models are available.
  • [2] SIE option supports Crypto Erase, which is a standardized feature defined by NVM Express Inc.
  • [3] SED supports TCG Opal and Ruby SSCs. It has a few unsupported TCG Opal features. For more details, please make inquiries through "Contact us" .
  • [4] KIOXIA FIPS drives utilize a security module designed to comply with FIPS 140-2 Level 2 and FIPS 140-3 Level 2, which define security requirements for cryptographic module by NIST (National Institute of Standards and Technology). For the latest validation status, please make inquiries through "Contact us".
  • [5] Optional security feature compliant drives are not available in all countries due to export and local regulations.
  • PCIe is a registered trademark of PCI-SIG.
  • NVMe is a registered or unregistered mark of NVM Express, Inc. in the United States and other countries.
  • Other company names, product names, and service names may be trademarks of their respective companies.
