  • Description
  • Please Read

Enterprise NVMe™ Read-intensive SSD


KIOXIA CM7-R Series is a read-intensive SSD that is optimized to support a broad range of enterprise applications and associated workloads, including business intelligence, online transaction processing, and software defined storage and virtualization. Built on PCIe® 5.0 (for U.3 host: PCIe® 4.0) and NVMe™ 2.0 technology, the CM7 Series SSDs deliver excellent performance up to 2,700K IOPS (random read) and 310K IOPS (random write).

Featuring KIOXIA 112-layer BiCS FLASH™ 3D TLC flash memory, the CM7-R Series of enterprise NVMe™ SSDs delivers 1 DWPD (Drive Writes Per Day) of endurance and support storage capacities up to 30.72 TB, making them ideally suited for read-intensive enterprise applications.

Key Features


  • PCIe® 5.0 (for U.3 host: PCIe® 4.0), NVMe™ 2.0 specification compliant
  • Open Compute Project Datacenter NVMe™ SSD specification v2.0 support (not all requirements)
  • Form factor: 2.5-inch, 15 mm thickness
  • Proprietary KIOXIA architecture: controller, firmware and 112-layer BiCS FLASH™ 3D TLC
  • SFF-TA-1001 conformant (U.3)
  • Dual-port design for high availability applications
  • High performance with lower power consumption
  • Power loss protection (PLP) and end-to-end data protection
  • Suited for 24x7 enterprise workloads
  • Security options: SIE, SED, FIPS SED[1][2][3][4][5]

Key Applications

  • Software defined storage and virtualization
  • Data warehousing
  • Online transaction processing (OLTP)
    (transactional and relational databases)
  • Business intelligence
  • Artificial intelligence and machine learning

Specifications

* Table can be scrolled horizontally.

Base Model Number KCMY1RUG30T7 KCMY1RUG15T3 KCMY1RUG7T68 KCMY1RUG3T84 KCMY1RUG1T92
Capacity 30,720 GB 15,360 GB 7,680 GB 3,840 GB 1,920 GB
Basic Specifications
Form Factor 2.5-inch, 15mm thickness
lnterface PCIe® 5.0, NVMe™ 2.0
Maximum Interface Speed 128 GT/s (PCIe® Gen5 single x4, dual x2)
Flash Memory Type BiCS FLASH™ TLC
Performance in single port (1x4) mode (Up to)
Sustained 128 KiB Sequential Read 10,000 MB/s 14,000 MB/s
Sustained 128 KiB Sequential Write 4,900 MB/s 7,000 MB/s 6,750 MB/s 3,500 MB/s
Sustained 4 KiB Random Read 1,600K IOPS 2,400K IOPS 2,450K IOPS 2,700K IOPS 2,000K IOPS
Sustained 4 KiB Random Write 150K IOPS 300K IOPS 310K IOPS 155K IOPS
Power Requirements
Supply Voltage 12 V ± 10 %, 3.3 V ± 15 %
Power Consumption (Active) 25 W typ. 22 W typ.
Power Consumption (Ready) 5.5 W typ. 5 W typ.
Reliability
MTTF 2,500,000 hours
Warranty 5 years
DWPD 1
Dimensions
Thickness 15.0 mm +0 / -0.5 mm
Width 69.85 mm ± 0.25 mm
length 100.45 mm Max
Weight 130 g Max
Environmental
Temperature (Operating) 0 °C to 72 °C 0 °C to 73 °C 0 °C to 76 °C
Temperature(Non-operating) -40 °C to 85 °C
Humidity (Operating) 5 % to 95 % R.H.
Vibration (Operating) 21.27 m/s2 { 2.17 Grms } ( 5 to 800 Hz )
Shock (Operating) 9.8 km/s2 { 1,000 G } ( 0.5 ms )


  • Product image may represent a design model.
  • Definition of capacity: KIOXIA Corporation defines a megabyte (MB) as 1,000,000 bytes, a gigabyte (GB) as 1,000,000,000 bytes and a terabyte (TB) as 1,000,000,000,000 bytes. A computer operating system, however, reports storage capacity using powers of 2 for the definition of 1GB = 2^30 = 1,073,741,824 bytes and therefore shows less storage capacity. Available storage capacity (including examples of various media files) will vary based on file size, formatting, settings, software and operating system, and/or pre-installed software applications, or media content. Actual formatted capacity may vary.
  • GT/s: Giga Transfers per second.
  • A kibibyte (KiB) means 2^10, or 1,024 bytes.
  • MTTF (Mean Time to Failure) is not a guarantee or estimate of product life; it is a statistical value related to mean failure rates for a large number of products which may not accurately reflect actual operation. Actual operating life of the product may be different from the MTTF.
  • DWPD: Drive Writes Per Day. One full drive write per day means the drive can be written and re-written to full capacity once a day every day for the specified lifetime. Actual results may vary due to system configuration, usage and other factors.
  • Read and write speed may vary depending on various factors such as host devices, software (drivers, OS etc.), and read/write conditions.
  • IOPS: Input Output Per Second (or the number of I/O operations per second).
  • Temperature (operating): Specified by the composite temperature reported by SMART.
  • [1] The Sanitize Instant Erase (SIE), Self-Encrypting Drive (SED) and FIPS (Federal Information Processing Standards) SED optional models are available.
  • [2] SIE optional models support Crypto Erase, which is a standardized feature defined by the technical committees (T10) of INCITS (the InterNational Committee for Information Technology Standards).
  • [3] SED optional models support TCG Opal and Ruby SSCs. It has a few unsupported TCG Opal features. For more details, please make inquiries through “Contact us”.
  • [4] FIPS SED optional models utilize a security module designed to comply with FIPS 140-3, which define security requirements for cryptographic module by NIST (National Institute of Standards and Technology). For the latest validation status, please make inquiries through “Contact us”.
  • [5] Optional security feature compliant models are not available in all countries due to export and local regulations.
  • All information provided here is subject to change without prior notice.
  • PCIe is a registered trademark of PCI-SIG.
  • NVMe is a registered or unregistered mark of NVM Express, Inc. in the United States and other countries.
  • Other company names, product names, and service names may be trademarks of third-party companies.
